BackScan
A rear sensor system with visual and audible warnings of the vehicle’s distance from an object behind it. With a variety of mounting solutions, and an optional 50cm clearance selection for vehicles with tail lifts, this is an ideal solution for larger vehicles.
Product Specification
| Number of sensors | 4 |
| Detection Range | 0~2.5m |
| Operating Power | 12/24v |
| Tail Lift Adjustment | 50cm selectable on switch |
| Object detection | 200 milliseconds |
| False Alarm Protection | Environmental learning (up to 100cm protrusion) |
| Waterproof Rating | Control Module: IP69K, Sensors: IP68 |
| Alert | Graduated Audible and Visual |
| Mounting Rings | 0°, 11°, underhanging |
| Display Cable Length | 15m |
| Sensor Cable Length | 4 x 2.5m |
| Operating Temp | -40°C to +80°C |
| Certifications | CE & EMC approved: E |
Optional Extras
Articulated Vehicles
- SK-15-04 – Truck/Trailer camera and sensor display suzi cable kit
- SK-UDS-05 – Truck/Trailer sensor display only suzi cable kit
Extensions
- UDS-2.5BC – 2.5m Buzzer/display extension cable
- UDS-10BC – 10m Buzzer/display extension cable
- UDS-15BC – 15m Buzzer/display extension cable
- UDS-2.5SC – 2.5m Sensor extension cable
- UDS-4.5SC – 4.5m Sensor extension cable
Product Code: SEN-BS-4000W
